ECO POWER is committed to providing you with the best battery solutions.MS0202-51.52V228A-(228AH1P16S) consists of 16 cells connected in series with a rated voltage of 51.52V and a rated capacity of 228Ah. Whether you use it for electric vehicles, industrial and commercial energy storage or off-grid energy storage, it is your preferred choice.
To delve into the technical specifications, features, and advantages of the MS0202-51.52V228A-(228AH1P16S) battery, simply visit our product page. Our team of experts is dedicated to developing eco-conscious products that contribute to a sustainable future, and we take immense pride in the positive impact our batteries have on the environment.
| No. | Items | EP-LFP228Ah STANDARD MODULE | Note | |
| MS0202-51.52V228A | ||||
| 228AH1P16S | ||||
| 1 | Nominal voltage(V) | 51.52 | ||
| 2 | Operating voltage(V) | min | 40 | T＞0℃ |
| 3 | max | 58.4 | ||
| 4 | Nominal capacity(Ah) | 228 | 1/3C，100%DOD | |
| 5 | Nominal energy（KWh ） | 11.746 | 1/3C，100%DOD | |
| 6 | Cell Configuration | 1P16S | ||
| 7 | Maximum continuous charge current（A） | 228 | ||
| 8 | Maximum continuous discharge current（A） | 228 | ||
| 9 | Maximum pulse discharge current（≤180s）（A） | 456 | ||
| 10 | SOC operating range（%） | 10~90 | ||
| 11 | Insulation requirements(MΩ) | ≥20 | ||
| 12 | Module cooling method | Natural cooling | ||
| 13 | Module heating film | No | Or heating film | |
| 14 | Shipping capacity (SOC) | ≈30% | SOC is consistency in the same batch | |
| 15 | Dimension L （mm） | 964.8 | ||
| Dimension B （mm） | 178.6 | |||
| Dimension H （mm） | 223.4 | |||
