MS0202-35.42V228A-(228AH1P11S) consists of 11 cells connected in series, with a rated voltage of 35.42V and a rated capacity of 228Ah.It can provide stable energy for electric light trucks, electric heavy trucks and other applications.
Explore our product page to delve into the technical specifications, features, and benefits of the MS0202-35.42V228A-(228AH1P11S) battery. Join countless satisfied customers who have already made the switch to EcoPowerBattery and experience the future of sustainable energy solutions. With our commitment to eco-conscious practices and customer satisfaction, we strive to lead the way toward a greener and more energy-efficient world.
| No. | Items | EP-LFP228Ah STANDARD MODULE | Note | |
| MS0202-35.42V228A | ||||
| 228AH1P11S | ||||
| 1 | Nominal voltage(V) | 35.42 | ||
| 2 | Operating voltage(V) | min | 27.5 | T＞0℃ |
| 3 | max | 40.15 | ||
| 4 | Nominal capacity(Ah) | 228 | 1/3C，100%DOD | |
| 5 | Nominal energy（KWh ） | 8.075 | 1/3C，100%DOD | |
| 6 | Cell Configuration | 1P11S | ||
| 7 | Maximum continuous charge current（A） | 228 | ||
| 8 | Maximum continuous discharge current（A） | 228 | ||
| 9 | Maximum pulse discharge current（≤180s）（A） | 456 | ||
| 10 | SOC operating range（%） | 10~90 | ||
| 11 | Insulation requirements(MΩ) | ≥20 | ||
| 12 | Module cooling method | Natural cooling | ||
| 13 | Module heating film | No | Or heating film | |
| 14 | Shipping capacity (SOC) | ≈30% | SOC is consistency in the same batch | |
| 15 | Dimension L （mm） | 695.8 | ||
| Dimension B （mm） | 178.6 | |||
| Dimension H （mm） | 223.4 | |||
