EP-48V1000Ah

EP-48V1000Ah Telecom Energy Storage System provides high-capacity energy storage to ensure continuous operation of telecom equipment during grid instability or power outages. Featuring LFP battery technology, it offers high safety, long lifespan (>2000 cycles), and intelligent BMS management. Ideal for 5G base stations, data centers, and remote telecom sites.


UPS   System Specification
NOItemParameters
1Battery CellBattery ModelLifepo4/3.2v12.5AH
2Nominal capacity12.5Ah
3Nominal voltage3.2V
4Internal Resistance   (1KHZ AC )6~8MΩ
5Operating   Voltage2.5~3.65V
6Standard Currents for   Charing and Discharging3.6A
7Max.Continuous   Discharging current12A
8Max.Pluse Discharging   Current (long pluse)24A(3min)
9Max.Pluse Discharging   Current(short pluse)36A(10S)
10WeightApprox 0.45kg
1148V100AH   Battery packNominal   voltage51.2V
12Nominal   Energy(20±5℃0.3C@100%DOD)5.12KWH
13Battery   System Configuration8   parallel and 16 serial of single battery cells
14Battery   System Operating Voltage Range43.2V~56.8V
15Floating   Charging Voltage53~54.4V
16System   Maximal Charging Current20A
17System  Maximal Discharging Current80A~90A
1848V1000AH   Battery systemNominal   voltage51.2V
19Nominal   Energy(20±5℃0.3C@100%DOD)51.2KWH
20Battery   System Configuration10   parallel  of 48V100AH packs
21Battery   System Operating Voltage Range43.2V~56.8V
22Floating   Charging Voltage53~54.4V
23System   Maximal Charging Current200A
24System   Maximal Discharging Current800A~900A
25Application:*Single cells *48V100AH Battery Pack   *48V1000AH Battery SystemOperating Temperature   Range0~45℃
26Recommended Operating   Range of SOC10%~90%
27SOC Requirement for   long period idle and storage30%SOC
28Short term (1   month)Storage Temperature﹣20℃~45℃
29Long  term (1 year)Storage Temperature﹣20℃~25℃
30Storage Humidity﹤70%
31Operating   Humidity﹤80%
32Insulation Resistance≥10MΩ
33Communication to   ExternalRS485
34Cycle Life≥2000time
35Battery warranty5 Years
Note:


1.It   is required to install and operate the system in a indoor environment with   temperature about 30~35℃
2.The   system must be charged with the specified    lithium Battery compactible charger
