MS0202-38.64V302A-(302AH1P12S) It is designed with a standard capacity of 302Ah and a standard voltage of 38.64V. It also has a built-in Battery Management System (BMS), which makes the module's operation more reliable and safer. The module is also very durable and can withstand a wide range of temperatures.
| Items | EP-LFP302Ah STANDARD MODULE | Note | |
| MS0202-38.64V302A | |||
| 302Ah1P12S | |||
| Nominal voltage(V) | 38.64 | ||
| Operating voltage(v) | min | 30 | T＞0%℃ |
| max | 43.8 | ||
| Nominal capacity (Ah) | 302 | 1/3C，100%DOD | |
| Nominal energy (KWh) | 11.669 | 1/3C，100%DOD | |
| Group mode | 1P12S | ||
| End of life residual capacity (Ah) | 241.6 | ||
| Module weight (Kg) | 67.94 | ||
| Maximum continuous charge current (A) | 302 | ||
| Maximum continuous discharge current (A) | 302 | ||
| Maximum pulse discharge current (≤30s)(A) | 604 | ||
| SOC operating range (%) | 10~90 | ||
| Insulation requirements(MΩ) | ≥20 | ||
| Module cooling method | Natural cooling | ||
| Module heating film | No | Or heating film | |
| Shipping capacity (SOC) | ≈30% | SOC is consistency in the same batch | |
| Dimension L (mm) | 963.6 | ||
| Dimension B (mm) | 180 | ||
| Dimension H (mm) | 225 | ||
